HomeGlide stairlift
1.2 Major parts
Ingure1.1youseeaschematicoverviewoftheHomeGlidestairlift.The
majorpartsareindicatedwithlines.
TIP
Figure 1.1 shows the standard arrangement for a right-handed
user with the control unit on the right hand armrest.
Descriptiongure1.1:
a. folding seat
b. rail
c. control unit
d. backrest
e. folding armrest
f. safetybelt
g. swivel seat handle
h. drive unit
i. folding footrest
Fig. 1.1: Major parts
