ThyssenKrupp HomeGlide - Control Unit Operation

12
HomeGlide stairlift
2.1.2 Control unit
Assoonasyouinsertthejoystickinthecontrolunit,youcan,whilesitting
on the seat, control the stairlift with a single hand movement. The control
unitismountedontherightarmrestinthefactory.
2.1.3 Main switch
WiththemainswitchyoucanturntheHomeGlidestairliftonandoff(for
instancewhenyouwillgoonaholiday,orwhenyouarenotathomefora
long time).
Fig. 2.1: Call and send station
a. Call and send buttons
b. Holder
Fig. 2.2: Control unit
d
a
TIP
Thestairliftwillnotmoveifthejoystickisnotplacedinthe
control unit.
a
b
