Thytronic NG10 User Manual

APPENDIX
148
NG10 - Manual - 04 - 2022
Value s 0.10 ... 10.00 step = 0.01
BLIN maximum activation time for ground protections
Value s 0.10 ... 10.00 step = 0.01
tB-Iph/IE Elapsed signalling relays tB-K K1 | K2 | K3 | K4 | K5 | K6
tB-Iph/IE Elapsed signalling LEDs tB-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Selective block OUT
BLOUT1 Selective block operating mode ModeBLOUT1 OFF | ON IPh/IE | ON IPh | ON IE
BLOUT Dropout time for phase protections
Value s 0.00 ... 1.00 step = 0.01
BLOUT Dropout time for ground protections
Value s 0.00 ... 1.00 step = 0.01
BLOUT Dropout time for ground and phase protections
Value s 0.00 ... 1.00 step = 0.01
Phase protections output selective block relays BLK2OUT-Iph-K K1 | K2 | K3 | K4 | K5 | K6
Ground protections output selective block relays BLK2OUT-IE-K K1 | K2 | K3 | K4 | K5 | K6
Phase and ground protections output selective block
relays
BLK2OUT-Iph/
IE-K
K1 | K2 | K3 | K4 | K5 | K6
Phase protections output selective block LEDs BLK2OUT-Iph-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Ground protections output selective block LEDs BLK2OUT-IE-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Phase and ground protections output selective block
LEDs
BLK2OUT-Iph/IE-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Breaker failure - BF
BF Enable BF Enable OFF | ON
BF Phase current threshold
State OFF | ON
Pickup value InH 0.05 ... 1.00 step = 0.01
BF Time delay
Value s 0.06 ... 10.00 step = 0.01
BF Logical block BF-BLK1 OFF | ON
BF Start from circuit breaker CB Input OFF | ON
BF Start relays BF-ST-K K1 | K2 | K3 | K4 | K5 | K6
BF Trip relays BF-TR-K K1 | K2 | K3 | K4 | K5 | K6
BF Start LEDs BF-ST-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
BF Trip LEDs BF-TR-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
PLC
Setpoints
Enable PLC Enable OFF | ON
Relays PLC-K K1 | K2 | K3 | K4 | K5 | K6
LEDs PLC-L START | TRIP | L1 | L2 | L3 | L4 | L5 | L6
Switches
Switch 1 0 | 1
Switch 2 0 | 1
Switch 3 0 | 1
Switch 4 0 | 1
Switch 5 0 | 1
Switch 6 0 | 1
Switch 7 0 | 1
Switch 8 0 | 1
Switch 9 0 | 1
Switch 10 0 | 1
Switch 11 0 | 1
Switch 12 0 | 1
Switch 13 0 | 1 | 2
