APPENDIX
156
NG10 - Manual - 04 - 2022
Binary 28
Id>-L1 ST | Id>-L2 ST | Id>-L3 ST | Id>-L1 TR | Id>-L2
TR | Id>-L3 TR | Id>>-L1 ST | Id>>-L2 ST | Id>>-L3
ST | Id>>-L1 TR | Id>>-L2 TR | Id>>-L3 TR | SatDet
ST | Off
Binary 29
Id>-L1 ST | Id>-L2 ST | Id>-L3 ST | Id>-L1 TR | Id>-L2
TR | Id>-L3 TR | Id>>-L1 ST | Id>>-L2 ST | Id>>-L3
ST | Id>>-L1 TR | Id>>-L2 TR | Id>>-L3 TR | SatDet
ST | Off
Binary 30
Id>-L1 ST | Id>-L2 ST | Id>-L3 ST | Id>-L1 TR | Id>-L2
TR | Id>-L3 TR | Id>>-L1 ST | Id>>-L2 ST | Id>>-L3
ST | Id>>-L1 TR | Id>>-L2 TR | Id>>-L3 TR | SatDet
ST | Off
Binary 31
Id>-L1 ST | Id>-L2 ST | Id>-L3 ST | Id>-L1 TR | Id>-L2
TR | Id>-L3 TR | Id>>-L1 ST | Id>>-L2 ST | Id>>-L3
ST | Id>>-L1 TR | Id>>-L2 TR | Id>>-L3 TR | SatDet
ST | Off
Binary 32
Id>-L1 ST | Id>-L2 ST | Id>-L3 ST | Id>-L1 TR | Id>-L2
TR | Id>-L3 TR | Id>>-L1 ST | Id>>-L2 ST | Id>>-L3
ST | Id>>-L1 TR | Id>>-L2 TR | Id>>-L3 TR | SatDet
ST | Off
Communication
RS485
Protocol MODBUS
Address 1 ... 254 step = 1
Baudrate RS485
1200 baud | 2400 baud | 4800 baud | 9600 baud |
19200 baud | 38400 baud | 57600 baud
Ethernet
IP host address
IP net mask
IP gateway
Autonegotiation OFF | ON
NTP
Enable OFF | ON
Type Local Network | Internet | User
NTP Server
Zurich(Europe) | Berlin(Europe) | Italy(Europe)
| Fukuoka1(Japan) | Fukuoka2(Japan) |
Pushchino(Russia) | Lagos(Nigeria) | South Africa
NTP Server address
Time Zone
(UTC+0) - Greenwich Dublin Edinburgh Lisbon
London | (UTC+1) - Amsterdam Berlin Bern Rome
Stockholm Vienna | (UTC+2) - Athens Bucharest
Cairo Instanbul | (UTC+3) - Addis Abeba Baghdad
Moscow Nairobi S.Petersburg | (UTC+4) - Baku
Dubai Mauritius Samara Tbilisi | (UTC+5) - Karachi
Maldives Tashkent Yekaterinburg | (UTC+6) - Al-
maty Dhaka Omsk | (UTC-1) - Azores CapoVerde |
(UTC-2) - Mid Atlantic | (UTC-3) - Brasilia BuenosAi-
res Georgetown Greenland | (UTC-4) - AtlanticTime
LaPaz Manuas Santiago | (UTC-5) - EasternTime
(US Canada) Indiana | (UTC-6) - CentralTime (US
Canada) CentralAmerica
Daylight saving time Disable | Europe | Russia | Jordan | Syria | Egypt
NTP sychronization LED None | START | TRIP | L1 | L2 | L3 | L4 | L5
Network management
Enable OFF | ON
Type Multicast | Broadcast
Multicast address
Broadcast address
Rx port 0 ... 20000 step = 1
Tx port 0 ... 20000 step = 1
