FUNCTION CHARACTERISTICS

NG10 - Manual - 04 - 2022

Breaker failure (BF)

The element can produce the Breaker Failure side H output if the 64REF-BF, parameter is set to

ON. The parameters are available inside the Set \ Proﬁle A(or B) \ Low impedance restricted ground

fault-64REF menu.

[1]

The following block criteria are available:

Logical block (Block1)

If the 64REF-BLK1 enabling parameter is set to ON and a binary input is designed for logical block

(Block1), the element is blocked off whenever the given input is active.

[2]

The enabling parameters

are available inside the menu Set \ Proﬁle A(or B) \ Low impedance restricted ground fault - 64REF

menu, while the Block1 function must be assigned to the selected binary input inside the Set \ Inputs

\ Binary input IN1(x) menus.

Selective block (Block2)

For the protective element the output selective block may be set.

The logic selectivity function may be performed by means any combination of the following I/O:

• One committed pilot wire output (BLOUT1).

• One or more output relays designed for output selective block.

Only when the committed pilot wire are used the continuity check of the pilot wire link is active.

Use of committed pilot wire output BLOUT1:

• The information about phase or phase+earth block may be select programming the ModeBLOUT1

parameter (OFF-ONIPh-ONIPh/IE-ONIE) inside Set \ Proﬁle A(or B) \ Selective block-

BLOCK2 \ Selective block OUT menus.

Use of output relay (K1...K6):

• If the 64REF-BLK2OUT enable parameter is set to ON and a output relay is designed for selective

block (Block2), the protection issues a block output by phase elements (BLK2OUT-Iph) or by any pro-

tection element (BLK2OUT-Iph/IE), whenever the given element (Start 64REF) becomes active. The

enable 64REF-BLK2OUTparameter (ON or OFF) is available inside the Set \ Proﬁle A(or B) \ Low

impedance restricted ground fault - 64REF, while the BLK2OUT-Iph-K, BLK2OUT-Iph/IE-K

and/or BLK2OUT-IE-K output relays and LEDs (BLK2OUT-Iph-L, BLK2OUT-Iph/IE-L e/o

BLK2OUT-IE-L) must be select inside the Set \ Proﬁle A(or B) \ Selective block-BLOCK2 \ Selec-

tive block OUT menu.

Note 1 The common settings concerning the Breaker failure protection are adjustable inside the Breaker Failure - BF menu.

Note 2 The exhaustive treatment of the logical block (Block 1) function may be found in the “Logic Block” paragraph inside CONTROL AND MONITOR-

ING section

Thytronic NG10 User Manual
