FUNCTION CHARACTERISTICS
• δ angle oscillation frequency out of range 0.2 Hz÷8 Hz
78 Protection Functional
Diagram
78 Parameters calculation
example
WARNING
All regulations must be established according to accurate ElectroMagnetic Transient study (EMT).
All values presented in following calculation example are for education purpose ONLY and they
cannot be used for real application.
