15.4.6 Generic Temperature/Humidity/Pressure, Altitude
Generic Temperature/Humidity/Pressure ,Altitude
1SM Outputs
TE1151-12
SM Channel
Digital Output
Device
1
1
Fan
2
2
High Artificial Load
3
3
PID Heat
4
4
Boost Heat
5
5
Low Compressor
6
6
High Compressor
7
7
PID Cool
8
8
Full Cool
9
9
Low Artificial Load
10
10
Cascade
11
17
Vent BC
12
18
Vacuum
2SM Outputs
TE1151-6
SM Channel
Digital Output
Device
1
11
Ambient
2
12
PID Humidity
3
13
Dehumidify Coil
4
14
Hi Al
5
15
Drier
6
16
Wickpan
3SM Event Outputs
TE1151-6
SM Channel
Digital Output
Device
1
19
Event 1
2
20
Event 2
3
21
Event 3
4
22
Event 4
5
23
Event 5
6
24
Event 6
SSR Outputs
TE1151-5
SM Channel
Digital Output
Device
1
25
Ambient
2
26
PID Humidity
3
27
Dehumidify Coil
4
28
Drier
5
29
Wick Pan
6
30
Two
