x Page 6 xPre-Delivery Instructions Page 6
61" (154.9 cm)
54 1/2" (138.4 cm)27 3/4" (70.5 cm)
18" (46 cm) 18" (46 cm)
22" (55.9 cm)
36" (91.4 cm)
3 1/2" (8.9 cm)
27" (68.6 cm)
29 1/2" (74.9 cm)
33" (83.8 cm)
MAIN DRAIN
1 3/4" (3.8 cm) ELECTRICAL CUTOUT
(location may vary 1/2" (1.3 cm) )
UPSIDE DOWN VIEW OF SPA
55 1/4" (140.3 cm) 27" (68.6 cm)
DOOR SIDE
79" (2.01 m)
17 1/4" (43.8 cm) 17 1/2" (44.5 cm)
19 3/4" (50.2 cm)
20 1/4" (51.4 cm)
86 1/2" (2.2 m)
CENTER MIDDLE SHIMS
13 1/2" (34.3 cm)
68" (173.0 cm)
SECONDARY DRAIN
Bengal
®
(Model M & MM)
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
(Front view)
(Bottom view)
• 15 Leveling Points (place shims approx. 18” in from edge, then center middle shims)
