x Page 7 xPage 7 Pre-Delivery Instructions
61" (155 cm)
57" (144.8 cm)
29 1/4" (74.3 cm) 44 1/2" (113 cm)
15" (28 cm) 15" (28 cm)
43 1/2" (110.5 cm)
17 1/2" (44.5 cm)
3 1/2" (8.9 cm)
27" (68.6 cm)
29 1/2" (74.9 cm)
33" (83.8 cm)
MAIN DRAIN
1 3/4" (3.8 cm) ELECTRICAL CUTOUT
(location may vary 1/2" (1.3 cm) )
UPSIDE DOWN VIEW OF SPA
48" (121.9 cm) 25 3/4" (65.4 cm)
DOOR SIDE
78" (1.98 m)
17 1/2" (44.5 cm)
19 1/4" (48.9 cm) 18 1/2" (47 cm) 18 1/2" (47 cm)
78" (1.98 m)
CENTER MIDDLE SHIMS
15" (38 cm)
SECONDARY DRAIN
Sumatran
®
(Model N)
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
(Front view)
(Bottom view)
• 15 Leveling Points (place shims approx. 15” in from edge, then center middle shims)
