Side Rotary Common Section 6 - 35
CASTER WHEEL ASSEMBLY
ITEM PART NO. QTY. DESCRIPTION
1 21459 1 SPINDLE, CASTER WHEEL AXLE
2 21987 5 LOCKWASHER, 5/16”
3 21575 5 HEX NUT, 5/16”
4 28548 5 CAPSCREW, 5/16” x 3/4”, NC
5 22697-1 1 RIM, OUTER/RR RTRY CASTER ASSY
6 21416 1 TIRE,SOLID,RR-RTRY
7 22696-1 1 RIM,REAR ROTARY CASTER
8 22070 1 DUST CAP
9 22533 1 COTTER PIN, 3/16” X 2”
10 6T0836 2 CUP, CASTER WHEEL
11 22073 1 HEX NUT,1NF(SLOTTED JAM NUT)
12 22071 5 HUB STUD
13 22066-1 1 HUB CASTER (REAR ROTARY)
