BACKSIDE INSTRUCTION

The recommend (from left to right):

1) power plug

2) Load cell

LOAD CELL

CONNECTOR PIN #

ASSIGNMENT

EXCITATION +ve

SENSE +ve

EXCITATION -ve

SENSE -ve

SIGNAL +ve

SIGNAL -ve

GROUND

3) Com1 RS232

RS232 COMPORT ON

INSTRUMENT

1 = GND

2 = TXD

3= RXD

IF USE CABLE

GLANDS,LOADCELL AND

RS232 CABLE NEED TO GO

THROUGH GLANDS TO

CONNECT ON THE PCB.

FOLLOW THE RIGHT POSITION

SIGN OF CONNECTION

PRINTED ON PCB
