www.timberk.com • Electric drier for changing of air humidity
3
2. SAFEGUARDS
1. DON’T CLOSE VENTS! Make sure that vent inlet and outlet are free.
2. Don’t insert foreign objects in air-outlet grille of the drier. It is very
dangerous, since the fan revolves at high speed.
3. Install the appliance only on a horizontal surface to avoid water leakage.
4. Don’t install the appliance in the following locations:
- where it is exposed to direct sunlight;
- near sources of open flame;
- near other working heating appliances;
- where the appliance may be exposed to water splashes or steam.
5. Don’t use the appliance in explosive or corrosive environment. Don’t
keep petrol and other volatile flammable liquids near the drier – it’s very
dangerous!
6. Don’t use the appliance only for drying (reducing of humidity level) of air
in domestic premises.
7. Clean the filter occasionally to ensure efficient work of the appliance.
8. To ensure reliable work of the compressor, don’t incline the appliance.
9. To avoid electric shock, a damaged power cord should be replaced only
in authorized service centers by qualified specialists.
10. Connect the appliance only to 220-230V~50Hz network. If needed,
find out characteristics of your network from power suppliers
3. SPECIFICATIONS
Model DH TIM 20 E7 DH TIM 25 E7
Capacity of draining (L/d) 20 25
Water tank volume (L) 3 3
Rated power consumption (W) 440 550
Power supply, V/Hz 220~/50 220~/50
Rated power current (A) 2,1 2,6
Air circulation m
3
/h 170/150 170/150
Noise level dB(A) 48/45 48/45
Refrigerant R135A R135A
Electrical protection class I class I class
Degree of protection against moisture IPX0 IPX0
Filling of Freon, g 105 120
Operating temperature range: ° C 5-35 5-35
Net weight (kg) 14,0 13,5
Gross weight (kg) 15,1 15,0
Net dimensions (mm) 330x260x420 330x260x420
Packing dimensions (mm) 365x285x505 365x285x505
Specifications are shown in table below.
