6. DELIVERY SET
1. Built-in electric hob – 1 pc.
2. Installation set (clamps – 2 pc.; screw – 2 pc.)
3. Foam – 1 pc.
4. Instruction manual – 1 pc.
5. Warranty card – 1 pc.
6. Packaging - 1 pc.
7. BEGINNING
UNPACKING THE INSTRUMENT
Remove the packaging and remove the device. If you have any doubts, do not use the appliance
and contact your dealer.
Some parts of the appliance are protected by a plastic film. This protective film must be removed
before using the instrument. Packaging materials should be carefully disposed of and kept out of
the reach of children as they represent a potential hazard.
8. INSTALLATION
The appliance must be installed and connected in accordance with current regulations.
After unpacking the appliance, ensure there is no visible damage. If it has been damaged
during transit, DO NOT USE, contact where you buy immediately.
Selection of installation equipment
-Cut out the work surface according to the sizes shown in the drawing.
-For the purpose of installation and use, a minimum of 5 cm space shall be preserved
around the hole.
-Be sure the thickness of the work surface is at least 30mm.
Please select heat-resistant work surface material to avoid larger deformation caused by
the heat radiation from the hotplate. As shown below (measure by unit: mm):
Fig. 3
