3. Technical Specifications
• 230V AC 50 Hz
• This time switch is of class I construction
and must be earthed
• Switch Rating: 13A resistive (3kW)
400W filament lighting
60W Fluorescent/
CFL lighting
• Programme: 24 hour
• Minimum setting interval: 15 minutes
• Minimum ON/OFF time
between setting: 30 minutes
• Up to 24 ON & OFF programmes per day
(additional pins required).
• Operating temperature: 0°C to +40°C
• CE Approved
• Manual Override: Self-cancelling manual
override to the next
programme change.
Note: Not suitable for use with
LED or Discharge Lighting.
