6. Operation
• Decide what times you would like the time switch
to switch ON and OFF.
• Insert a pin in the Inner Circle for an ON period.
• Insert a pin in the Outer Circle for an OFF period.
• The minimum switching interval is 30 minutes,
and this can be increased in 15 minute steps.
• Set the correct time of day by rotating the dial
clockwise until the correct time is indicated
by the Time indicator at the top centre of
the time switch.
Points to note
• Unused setting pins can be stored in the top left
and top right of the time switch.
• Remember to reset the time following
power failure.
