Note: The 230V 50Hz mains supply and load
cables can also enter through the cable entry ports
provided at the bottom of the unit. If you are not
wiring through the rear entry knock outs, use the
cable clamps provided to secure the cables.
• Terminate the supply and load cables to the
terminal block ensuring correct polarity is
observed and that all bare conductors
are sleeved. Please note the connections are
marked beneath the terminal block (see section 5.
Connection Diagram)
• Secure the terminal cover back into place
using the fixing screw
