2
Front Panel
Time Display
BATT LOW (Low Back-up
Battery Warning Indicator)
ALM 2 (Alarm 2) Indicator
ALM 1 (Alarm 1) Indicator
PM Indicator
Activating the Backup Batteries
• Remove the alarm clock and the AC power adapter from the carton.
Remove all packing material from the alarm clock. The carton is
recyclable.
• The CR2032 lithium back up battery has been pre-installed in the battery
compartment on the back panel. To activate the back up battery circuit,
remove the clear battery insulation tab by pulling the tab to the right as
shown in the illustration.
• When the battery low indicator appears on the display, the battery needs
to be replaced with a fresh battery. Press the point of a pin or paperclip
firmly into the hole by the battery compartment on the bottom of the unit
to release the cover. Slide the battery holder out (remove old battery if
replacing).Make sure battery polarity matches diagram (+ side facing up).
In the event of a power failure, the backup battery will maintain clock and
alarm settings.
• Fully unwind the cord of the AC power adapter. Connect the female plug
of the adapter to the DC jack on the back panel of the clock. Insert the
AC plug of the adapter into a normal AC outlet. We suggest that you use
an outlet that is always ‘live’, not an outlet controlled by a wall switch.
RESET
RESET
TEST
TEST
OPEN
To Next Page
