Appendix A: Specifications
A.1 Electrical Specifications
Table 3: Table 3 lists the electrical specifications for the 4033A.
Table 3: Electrical specifications
Item Specification
Protection Class Class I (Grounded Type)
Power Input Voltage
100 – 240 V~ 50/60 Hz 0.5 A
Note: Fluctuations not to exceed ± 10% of nominal supply voltage.
Power Inlet Type IEC 60320 sheet C14
Power Supply Cord Set
18 AWG (0.75 mm
2
minimum)
Power Mains Fuse (2) - 250V~1A Time lag 5x20 mm
Signal Input
 Impedance: 50
 Logic one > 2.4 V
 Logic zero < 0.8 V
 1 PPS to 1 MPPS
 Duty Cycle 0-50%
Connectors
 Input: 1 BNC
 Output: 15 BNC
 LAN: RJ-45
Output voltage
 Logic one : + 4.5 V minimum into 50 Ω
 Logic zero : + 0.8 V Maximum into 50 Ω
Pulse rise time < 2.0 ns
Pulse fall time < 2.0 ns
Skew between outputs < ± 2 ns
Jitter < 50 ps rms
Output impedance
50 Ω
