2.2.2 Cable
The actuator is supplied with a power cable (and/or signal cable). The standard cable, for industrial
applications, has/have flying leads in the end for the user’s equipment connections.
*Please refer to the approval drawing of any customized cable/connector.
Cable without signal:
Cable with signal:
Φ1.5mm
mm
Φ4.6mm
mm
Power cable: 20AWG
Power cable: 20AWG
Power cable: 26AWG
Φ1.5mm
mm
Φ5.0mm
mm
Φ1.0mm
mm
