Tinker&Rasor SR-2 - Page 8

Web: www.tinker-rasor.com E-mail: Info@tinker-rasor.com
107-108
– 8 –
CORROSION MITIGATION INSTRUMENTATION
P. O. BOX 1667 SAN BERNARDINO, CA 92402 TEL: (909) 890-0700 FAX: (909) 890-0736
PRODUCT INSTRUCTIONS
MODEL SR-2 SOIL RESISTIVITY METER
PICTURE 1:
Model DL
-
1
Data Logger
connector
Battery
Charger
connector
Battery
Charger
indicator LED
START HERE
line of
RANGE
SELECTOR
switch
RANGE
SELECTOR
switch
LCD Display
LOW
BATTERY
Indicator LED
PUSH TEST
button
C1, C2, P1 &
P2
Terminal Posts
2
-
PIN, 4
-
PIN
METHOD
Pin selection switch
