TiPX Marker Parts List
ITEM
NO. QTY. PT. NO. DESCRIPTION
1 1 TA20002 Receiver, Black, Right
1 1 TA20201 Receiver, Tan, Right
2 1 TA20001 Receiver, Black, Left
2 1 TA20200 Receiver, Tan, Left
3 1 TA20042 Magazine Release
Actuator
4 1 TA20040 Magazine Release
5 1 TA20029 Trigger
6 1 TA20037 Actuator Link
7 1 TA20124 Puncture Valve Complete
8 2 TA20036 LHSH Cap Screw
9 1 TA07074 Bolt
10 4 98-01A LHSH Cap Screw
11 7 TA02060 Hex Nut
13 1 TA20051 Spring
14 1 TA20053 CO2 Cap Receiver Insert
15 1 TA20107 CO2 Cap Assembly
16 1 TA20043 Breech Window
17 1 TP01018 “T” Jewel (not shown)
19 1 TA20112 Gas Line, Long
20 1 TA20113 Gas Line, Short
21 1 TA20123 Regulator Complete
22 1 TA20110 Safety
23 1 TA20105 Air Valve Complete (with
Firing Valve)
24 1 FA-18 Ball Latch
25 1 TA20027 Barrel Adapter
26 1 TA20012 Barrel Shroud
27 1 TA20006 TiPX Barrel
28 1 TA20046 O-ring
29 1 02-40 O-ring
30 4 TA20096 O-ring
31 1 FA-07 Safety O-ring (black)
32 1 98-55 Safety O-ring (red)
33 1 TA20063 Trigger Pin, Long
Puncture Valve Assembly parts
34 1 TA07089 Snap Ring
35 1 TA20069 Washer
36 1 TA20034 Puncture Seal
37 1 SL2-25 O-ring
38 1 TA20115 Puncture Piston
39 1 TA20015 Spring
40 1 TA20048 Spring
41 1 TA20031 Puncture Pin
42 1 TA20049 O-ring
TiPX Marker Parts List
ITEM
NO. QTY. PT. NO. DESCRIPTION
43 1 TA20094 Puncture Valve Body
44 1 TA20039 Puncture Pin Cap
Firing Valve Assembly parts
45 2 TA20047 O-ring
46 1 TA20004 Firing Valve Body
47 2 TA20052 Screws
48 2 TA20008 O-ring
49 1 TA20014 Valve Bushing
50 1 TA20030 Firing Valve Pin Guide
51 1 TA20005 Actuator Pin
Air Valve Assembly parts
52 1 TA20085 Front Bolt Spring
53 1 SL2-4 Front Bolt O-ring
54 1 TA20109 Front Bolt
55 1 TA20077 Damper
56 1 TA20016 Power Tube
57 1 TA20010 O-ring
58 1 TA20009 Air Valve Body
59 1 TA20114 Valve Spool
60 2 TA20003 O-ring
61 2 SL2-25 O-ring
62 1 98-12A O-ring
63 1 02-88 Spring
64 1 TA20011 Air Valve End Cap
65 1 TA20035 Retaining Ring
Regulator Assembly parts
66 1 TA20119 Regulator End Cap
67 1 02-88 Spring
68 1 TA20080 Regulator Pin
69 1 TA20075 Regulator Pin Seat
70 1 TA20093 Regulator Body
71 1 TA20120 Regulator Piston
72 1 TA20081 Wear Disk
73 1 TA20038 Spring
74 1 TA20118 Pressure Relief Seal
Guide
75 1 TA20067 Spring
76 1 TA20068 Hollow Lock Set Screw
77 1 TA20023 Regulator Adjustment
Cap
78 1 TA20095 Regulator Plug
Magazine Assembly
79 1 TA20122 7 Ball Straight Feed
Magazine
