TIS 600 - Test Condition Parameters; Earth Resistance Test Conditions; Insulation Resistance Test Conditions; Leakage Current Test Conditions

Test Conditions:
Function
Range
Accuracy
Technical parameters
Earth Bond/
Earth
Resistance
test
0Ω~20Ω
±5%+3
Test current>200mA (R < 2Ω)
If 0.01~0.1Ω passed, display “√”
If 0.1~0.5Ω passed, display “√” and
flash
If 0.51~19.9 failed, display“×”
Test voltage 5VDC, test time 5S
Insulation
resistance test
Test voltage
500VDC
-
Test current> 1mA (R = 500KΩ)
Test time 5S
0.2MΩ~19.99MΩ
±5%+3
Test voltage
250VDC
-
Test current> 2mA (R = 1KΩ), test
time 5S
0.2MΩ~19.99MΩ
±5%+3
-
CLASS I
-
If ≥1MΩ passed, display “√”
CLASS II
-
If ≥2MΩ passed, display “√”
CORD
-
If ≥1MΩ passed, display “√”
Leakage
current test
0.10mA~10mA
±5%+3
Test voltage 50V rms, frequency
50Hz
Test time 5S
CLASS I
-
If 0.1~0.75mA passed, display “√”
If 0.75~3.5mA passed, display “√” and
flash
If 3.5~10.50mA failed, display “×”
CLASS II
-
If 0.1~0.25mA passed, display “√”
If 0.25~10.50mA failed, display “×”
CORD test
Correct
connection
Display “√PASS”
L open circuit
“LN ×, LE ×, NE √, OPEN”
N open circuit
“LN ×, LE √, NE×, OPEN”
G open circuit
“LN √, LE ×, NE ×, OPEN”
L_N short circuit
“LN ×, LE √, NE √, SHOR”
L_G short circuit
“LN √, LE ×, NE √, SHOR”
N_G short circuit
“LN √, LE √, NE ×, SHOR”
L_N reverse
connection
“LN ×, LE √, NE √, CORS”
L_E reverse
connection
“LN √, LE ×, NE √, CORS”
N_E reverse
connection
“LN √, LE √, NE ×, CORS”
Multiple errors
“LN ×, LE ×, NE ×, FIAL”
Out-phase
detection
Correct
Display “LN √, LE√, NE√”
230VAC±15%
110VAC±15%
Zero cord off
Display “LN ×, LE√, NE×”
