Section 3: Required Build Materials
Spars needed:
(2) 8x500mm (main wing spars)
(2) 8x500mm (wingtip support)
(2) 4x400mm (aileron hinge)
(1) 3x200mm (hstab support)
(1) 3x60mm (vstab support)
(1) 3x200mm (rudder hinge)
(1) 3x500mm (elevator hinge)
Recommended motor & prop:
Recommended motor 2212 or 2216 – maximum size 28xx
Counterrotating 8-10” propellers
Recommended electronics:
TBS crossfire / ELRS / Dragonlink.
5.8ghz / 1.2ghz video (19x19 camera).
Matek F405-WTE flight controller or similar.
Matek M8Q-5883 GPS/Compass or similar.
(2) 35a BLHeli ESCs (place in the fuselage).
(4) Emax ES08MAII servos. 2 for ailerons, 1 for elevator, 1 for rudder (and one more if you
want a servo for a pan camera on the FPV deck).
Example battery for beginners:
Example battery for medium endurance:
Example battery for max endurance:
Misc:
2 750g rolls of Polymaker Polylite prefoamed LWPLA.
Polycarbonate, PETG or other high-temp filament for the motor mount.
Medium CA glue.
220x220x250 minimum size print bed (Ender 3).
Control horns (this one).
M3 threaded inserts (max 6mm height).
M3 bolts of various sizes.
(4) 6x3mm magnets
