Titan 15 ACTIVE - Electronic Parts List

R/N P/N PARTNAME DESCRIPTION QTY
1
313-2104900001R
LOGO 1
2
310-2104900000R
GRILLE 1
3
537-4001080801AR
SCREW
M4×8
4
4
513-4012130800AR
LEVEL 4
5
565-0534100000R
COPPERNUT
M5
2
6
537-5001250801AR
SCREW
M5×25
4
7
565-0537100000R
COPPERNUT
M5
2
8
ZD-70401-01R
WOOFER 1
9
200-2105000003R
BAFFLE 1
10
537-6001100801AR
SCREW
M6×10
4
11
249-2010490001R
PANEL 1
12
559-5001300071R
SCREW
M5*30
4
13
ZD-70100-01R
TWEETER 1
14
500-1200951100R
NUT 10
15
274-0400900786R
PLUG 6
16
321-4201202286R
NUT
M12×M8×42
10
17
537-5001200801AR
SCREW
M5×19.5
4
18
231-5000000222R
FOOT 2
19
201-2010490003R
HOUSING 1
20
500-5080400300AR
NUT
M5
4
21 500-8012600800AR
NUT
M8 8
22
243-2104900000R
HANDLE 2
23
537-8000135801AR
SCREW
8
24
ZC-47252-07R
AMPLIFIER
1
25
537-4001200801AR
SCREW
M4×20
12
26
293-2010470002R
KNOB
1
27
232-2105000001R
RIGHTELBOW
1
28 232-2105000002R
LEFTELBOW
1
29
053-1472511658R
LEDPCB
1
30
292-2010470002R
STACKCUP
2
31
534-8001200803AR
SCREW
M8×20
4
11.ASSEMBLYPARTSLIST
11
