12
12.ELECTRONICPARTSLIST
R/N P/N PARTNAME DESCRIPTION QTY LOCATION
1 031-2200512121R FUSE 50T040H 1
2 042-1003005001R POWERSWITCH RF-1003TV-5AC250V 1
3 044-2600000000R POWERSOCKET RF-2004 1
4 055-0305006133R
RIBBONCABLE
5PIN24AWGUL1007L=60mm 1
5 055-0310025133R 10PIN24AWGUL1007L=250mm 1
6 055-0402032311R 2pin18AWGUL1617L=320mm 1
7 055-0407005111R 7PIN18AWGUL1015L=50mm 1
8 060-0180120300R 18#C-022-8L=120MM 1
9 060-0180151004R C-022-6L=15018# 1
10 060-4180140112R WIRE 1617AWG18L=140mm 1
11 071-1100000000R CABLETIES 100MMYJ-100 8
088-1472520000R AMPBOARD 1
1 001-0229308050R RESISTOR 0.22Ω 2WJ 1 R56
2 001-0393108050R RESISTOR 39K2W5% 2 R24.25
3 001-0398810050R RESISTOR 0.39R5W5% 2 R22.23
4 001-0470308050R RESISTOR 4.7Ω 2WJ 1 R112
5 001-1000207051R RESISTOR 10RFMF1W5% 1 R131
6 001-1000308050R RESISTOR 10Ω 2WJ 1 R79
7 001-1001105050R RESISTOR 100Ω 1/4WJ 1 R34
8 001-1004208050R RESISTOR 100K2W5% 1 R7
9 001-1008708050R RESISTOR 0.1Ω 2W5% 6 R62.63.69.70.133.134
10 001-1803308050R RESISTOR 18K2W5%T66 1 R30
11 001-2203208010R RESISTOR 22K2W1% 1 R32
1
2
001-2209308050QR RESISTOR 2R22W5% 1 R33
13 001-4703107050R RESISTOR 470K1W5% 1 R21
14 004-3307000000R RESISTOR 10D-20 3 R26.27.28
1
5
006-0104051143AR CAPACITOR 1UF/50V20% 1 C76
16 006-1004061194R CAPACITOR 10uF/100V 1 C19
17 006-1006051243R CAPACITOR 10UF/25V#5*12 5 C52.68.74.75.92
18006-1014061153AR CAPACITOR 100UF/25V6.3*1120% 3 C29.30.51
1
9
006-1014081153AR CAPACITOR 100UF/35V8*1120% 1 C15
20 006-1021174293R CAPACITOR 1000U/100V/20% 2 C23.24
21 006-1024304109R CAPACITOR 1000UF/200V20%ECOSZDA102DA 2 C12.14
22 006-2201061173R CAPACITOR 22uF/63V20% 2 C71.80
23006-2204051143AR CAPACITOR 22UF/25V20% 1 C53
24 006-2291051163R CAPACITOR 2.2UF/50V10% 2 C36.72
25 006-4700051251R CAPACITOR 47uF35V 1 C20
2
6
006-4714102053AR CAPACITOR 470UF/35V10*2020% 2 C27.28
27 006-4714132063R CAPACITOR 470UF/50V20%13*20 2 C25.26
RIBBONCABLE
RIBBONCABLE
RIBBONCABLE
RIBBONCABLE
RIBBONCABLE
