13.ELECTRONICPARTSLIST
28 008-1021040005R CAPACITOR 102PF400VM 4 C10.11.17.22
29 013-2240320503R CAPACITOR 220NF100V7.5*5.0*8.0 ±5% 1 C64
30 013-3304025005R CAPACITOR 334/275VJ 2 C16%18
31 014-1040311028R CAPACITOR MKS2100nF100V10% 6 C21.31.32.81.99.100
32 014-1050411006R CAPACITOR 1UF/250V10% 1 C13
33 016-4741112201R CAPACITOR 0.47UF/100VP=15mm 10 C56&63.89.90
34 017-0190000000R IC NJM7815FATO-220F(JRC) 1 U4
35 017-1830000000R IC KIA7915TO-220KEC 1 U5
36 017-2700000000R IC TDA7294ST 1 U12
37 018-0101492116R TRANSISTOR 2SA1492TO-3P 1 Q21
38 018-0303856116R TRANSISTOR 2SC3856TO-3P 1 Q20
39 018-0304883113R TRANSISTOR 2SC4883A(SANKEN)TO-220F 1 Q25
40 018-2800112115
R
FIELDEFFECTTRANSISTOR J112GTO-92 3 Q12.22.23
41 018-4404229225R FIELDEFFECTTRANSISTOR IRFP4229PBFT0-247AC 2 Q17.18
42 018-7000460125
R
FIELDEFFECTTRANSISTOR IRFP460ATO-247AC 2 Q5.6
43 022-1040041316R TRANSFORMER EC40 1 T3
44 026-3334000170R INDUCTOR 33UH 1 L1
45 034-1119992508R BRIDGERECTIFIER RBV2510 1 D11
46 056-0102224400R JACK JS3962-2P-WAFER 2 CON5.7
47 056-0103003300R JACK 2PIN3.96PH 1 AC-IN
48 056-4102220000R JACK JS-1001-02 1 CON9
49 056-4105221100R JACK DJ2802-05 2 CON8A.CON8B
50 056-4110000000R JACK 10PIN2.54 1 CON6A
51 056-6107004150R JACK 7pinPH=3.96mm 2 CON7A.CON7B
52 066-0095010000R SWITCH TO-2P 1 TSW1
53 067-2200107000R DIODE HER107JAL 2 D9.10
54 067-2200207000R DIODE HER204 4 D12.13.14.15
55 067-2201620000R DIODE F16C20CTO-220 1 D16
56 067-2201620001R DIODE F16C20ATO-220 1 D17
57 067-2205100000R DIODE SB/SR5100DIP 4 D18.19.20.21
58 067-3304744000R DIODE IN4744A15V-1W 1 ZD3
59 071-1100000000R CABLETIES 100MMYJ-100 1
60 080-0210012016R INDUCTOR 13.6MH0.8MM230VAC 2 T1.2
61 082-0100000000R PHOTOCOUPLER PC-17K1KODENSHI 4 U2.13.14.16
088-1472520001R AMPBOARD 1
1 002-1000022050R RESISTOR 10Ω 5%1/10W0805 1 R114
2 002-1001032050R RESISTOR 100Ω 0805 ±5%1/8W 1 R91
3 002-1002032010R RESISTOR 1K1/8W1%0805 3 R29.103.110
4 002-1003032010R RESISTOR 10KΩ 1/8W1%0805 14
R54.55.58.60.66.68.72.52
8.89.106.107.127.132.
135
