15
15.ELECTRONICPARTSLIST
088-1472525000R LEDBOARD 1
1 001-1002105050R RESISTOR 1K1/4WJ 6
R113.115.117.119.121.
123
2 019-0379132200R POWERLED φ3mm 6 LED1&6
3 053-1472511658R PCB 64*64mm1.6T1OZ 1
4 055-1302044444R RIBBONCABLE L=440MM ±10UL1007#26 1 CON8&CON9
088-1472525501R AMPBOARD 1
1 002-1002032010R RESISTOR 1K1/8W1%0805 1 R41
2 002-1003032010R RESISTOR 10KΩ 1/8W1%0805 2 R37.42
3 002-2003032010R RESISTOR 20KΩ 1/8W1%0805 1 R52
4 002-2003403010R RESISTOR 2K08051%0.125W 1 R36
5 002-2203032010R RESISTOR 22K1/8W1%0805 1 R47
6 002-2205032010R RESISTOR 2.2M1/8W1%0805 1 R44
7 002-2703032010R RESISTOR 27K1/8W1%0805 1 R48
8 002-4701032010R RESISTOR 470Ω 1/8W1%0805 1 R43
9 002-4702032010R RESISTOR 4.7K1/8W1%0805 3 R39.40.49
10 002-4703032010R RESISTOR 47KΩ 1/8W1%0805 2 R45.46
11 002-4709032010R RESISTOR 4.7Ω 1/8W1%0805 1 R50
12 002-6802032050R RESISTOR 6.8K0805$5%1/8W 1 R51
13 007-1001052093R CAPACITOR 10PF100V5%0805COG 1 C45
14 007-1003062090R CAPACITOR 103/100V080510% 1 C37
15 007-1004052060R CAPACITOR 100nF50V5%0805 8
C34.38.39.41.44.46.47.
48
16 007-1014063090R CAPACITOR 1U/100V10%1206 2 C33.49
17 007-1802052060R CAPACITOR 1.8NF50V5%0805X7R 2 C42.43
18 010-2251602010R CAPACITOR T450A12251CMAP1 1 C40
19 017-5220000001R IC L78L05ABDSO-8ST 1 U10
20 017-7070000000R IC IR2011SPBF8PIN 1 U9
21 017-7110000000R IC ISL55001IBZSO-8intersil 1 U6
22 017-7120000000R IC TC7WH08FU(TE12LF)8PINSMD 1 U8
23 017-7130000000R IC TC7WH04FU8PIN 1 U7
24 018-2905401227R TRANSISTOR 2N5401SSOT-23KEC 1 Q7
25 018-2905551227R TRANSISTOR 2N5551SSOT-23KEC 1 Q8
26 019-0012003103R DIODE MURS120T3(Pk:SMB)ON 1 D26
27 053-1407001610R PCB FR-41.610Z150*80 1
28 067-2204148110R DIODE STLL4148SMD1206 3 D24.25.903
088-1472527200R POWERBOARD 1
1 006-1001051163R CAPACITOR SM10uF50V10% 1 C253
2 006-1011061143R CAPACITOR SM100uF25V10% 5 C257.260.261.262.263
3 006-2201051163R CAPACITOR SM22uF50V10% 13
C202.203.207.210.211.
218.219.230.231.236.259.
284.285
