4 017-1124000000R IC IR2153DDIP-8IR 1 U1
5 018-2800112115
R
FIELDEFFECTTRANSISTOR J112GTO-92 1 Q31
6 019-0311122001R POWERLED 204HD/E-ARED φ3 1 LED7
7 019-0322122001R POWERLED LED204GD/E-AGREEN φ3 1 LED8
8 020-1032120325R POTENTIOMETER RD16K12D0094-10K15Ax2 2 VR201.204
9 020-5052119425R POTENTIOMETER RD16K124A068-50KCBX2SII 2 VR-202.203
10 040-1400000000R SWITCH JPS2281EA 2 SW201.201
11 048-3000000000R POWERSOCKET NYS143J3Y13pin 1 J203
12 049-2507222016R JACKSOCKET LA11137PIN 2 J200.201
13 051-0500000000R POWERSOCKET RCAJK0200560N 1 J202
14 056-4110000000R JACK 10PIN2.54 1 CON6A
15 057-2545011241R JACK 24P 1 CON1
16 067-2200107000R DIODE HER107JAL 1 D5
088-1472527201R POWERBOARD 1
1 002-1000022050R RESISTOR 10Ω 5%1/10W0805 1 R294
2 002-1001032050R RESISTOR 100Ω 0805 ±5%1/8W 4 R200.201.215.216
3 002-1002032010R RESISTOR 1K1/8W1%0805 4 R8.142.143.324
4 002-1003032010R RESISTOR 10KΩ 1/8W1%0805 44
R1.2.9.14.129.132.133.13
7.138.141.203.204.206.20
7.220.213.214.217.218.21
9.230.231.232.233.237.23
8.245.246.267.272.275.28
0.281.284.287.288.289.29
6.321.322.325.9B.10B
5 002-1004032010R RESISTOR 100KΩ 1/8W1%0805 5 R235.236.239.240.254
6 002-1005022005R RESISTOR 1M0.1W0.5%25PPM0805 1 R326
7 002-1203032010R RESISTOR 12K1/8W1% 1 R134
8 002-1204032050R RESISTOR 120K0805 ±5%1/8W 1 R260
9 002-1503032010R RESISTOR 15K1/8W1%0805 4 R19.278.290.8B
10 002-1504032050R RESISTOR 150K0805 ±5%1/8W 1 R268
11 002-1803032010R RESISTOR 18K1/8W08051% 3 R11.13.16
12 002-1804022010R RESISTOR 0805180K1/10W1% 2 R270.323
13 002-2003032010R RESISTOR 20KΩ 1/8W1%0805 1 R140
14 002-2203032010R RESISTOR 22K1/8W1%0805 3 R10.251.252
15 002-2400032011R RESISTOR 24K1/8W08051% 2 R265.266
16 002-2703032010R RESISTOR 27K1/8W1%0805 2 R247.248
17 002-3003032010R RESISTOR 30KΩ 1/8W1%0805 1 R286
1
8002-3300032050QR
RESISTOR 33R1/8W5% 2 R17.18
19 002-3301032010R RESISTOR 330Ω 1/8W1%0805 1 R269
20 002-3302032010R RESISTOR 3.3K1/8W1%0805 2 R255.256
21 002-3651012010R RESISTOR 3.65K1%0805 2 R144.145
22 002-4701032010R RESISTOR 470Ω 1/8W1%0805 5 R202.241.242.243.244
16
16.ELECTRONICPARTSLIST
