17
17.ELECTRONICPARTSLIST
23
002-4702032010QR
RESISTOR 4.7K1/8W1%0805 2 R259.264
24 002-4703032010R RESISTOR 47KΩ 1/8W1%0805 4 R208.211.277.5B
25 002-5102032010R RESISTOR 5.1KΩ 1/8W1%0805 2 R273.274
26 002-5102032100R RESISTOR 51K±5%1/8W0805 1 R249
27 002-5602032010R RESISTOR 5.6KΩ 1/8W1%0805 2 R20.279
28 002-6801032010R RESISTOR 680Ω 1/8W1%0805 1 R6B
29 002-6802032050R RESISTOR 6.8K0805 ±5%1/8W 2 R250.253
30 002-6803032010R RESISTOR 68K1/8W1%0805 1 R139
31 002-8203032050R RESISTOR 82K0805 ±5%1/8W 2 R258.7B
32 006-2250040561R CAPACITOR 2.2UF/50V4*5.5MMK 1 C35
33 007-1001062060R CAPACITOR 100PFCP50V10%0805 5 C89.90.206.222.249
3
4007-1002052060QR
CAPACITOR SMD1nF50V5%0805 1 C3
35 007-1002062060R CAPACITOR 1nFCP50V10%0805 9
C7.200.201.208.209.238.2
58.290.291
36 007-1004062060R CAPACITOR 100nFCP50V10%0805 35
C2.5.6.91.93.94.242.243.
247.248.251.252.
264&283.288.289.92
37 007-1004079040R CAPACITOR 1U/50V,20%,4*5MM 1 C1
38 007-1005079040R CAPACITOR 10UF25V ±20% 4*5.4mm 1 C9
39007-1502052060QR CAPACITOR 1N5/50V5% 2 C1B.C2B
40 007-1802052060R CAPACITOR 1.8NF50V5%0805X7R 2 C233.234
41 007-2201062060R CAPACITOR 220PFCP50V10%0805 7
C204.205.212.213.215.
217.232
42 007-2204062060R CAPACITOR 220nF50V10%0805 1 C292
43 007-3300052060R CAPACITOR 33pF50VNPO5%0805 2 C235.239
44 007-3302062060R CAPACITOR 3.3NF/50V080510% 1 C246
4
5
007-3902052060QR
CAPACITOR 3N9/50V5% 1 C244
46 007-4704062070R CAPACITOR 470NF/50V080520% 1 C8
47 007-5602052060R CAPACITOR 5.6NF50V5%0805 3 C240.241.245
48 007-6803052060R CAPACITOR 68NF50V10%0805 1 C237
49 017-1370000000R IC NJM2068MSO-8B(JRC) 1 U16
50 017-5270000001R IC NJM4580MNJM-DMP8 12 U17&25.27.28.29
51 018-2905401227R TRANSISTOR 2N5401SSOT-23KEC 2 Q2.37
52 018-2905551227R TRANSISTOR 2N5551SSOT-23KEC 4 Q1.3.4.36
53 053-1472521300R PCB 141.8X142.8X1.6(mm) 1
54 067-2204148110R DIODE STLL4148SMD1206 12
D1.3.4.6.7.8.202.203.
204.205.206.207
55 067-3300016111R DIODE ZMM1616V0.5WLL34 2 ZD1.2
56 089-0500000012R SWITCH SS-22F20-G12 1 SW203
57 221-1472410000R LEDHOLDER M5*22.5mmWHITE 2 D305.306
