Titan 340CC - Operation Limitations

14 | Copyright © 2015 Airmotive Engineering Corp.
NOTE: Engine oil temperature should not be below 140°F during continuous
operation.
Oil Operating Temperatures
Oil Operating Pressures
Average Ambient Air Desired Oil Temperature Maximum Oil Temperature
Above 80°F 180°F 245°F
Above 60°F 180°F 245°F
30°F to 90°F 180°F 245°F
0°F to 70°F 170°F 225°F
Below 10°F 160°F 210°F
Operating Condition
Oil Pressure
Maximum
Oil Pressure Minimum Idling
Normal Operation 90 60 25
Start-up and Warm-up 100 — —
4.3 Operational Limitations
Engine Type Operation RPM HP
Fuel Cons.
(gal/hr)
Max Oil
Cons.
(qts/hr)
Max Cyl
Head
Temp (°F)
TITAN 340CC
Take-Off 2700 180 16.2 0.25
475
Recommended
Cruise
See
Below
See
Below
Varies 0.25
450
Recommended
Maximum limiting CHT is 475*F. During Climb-out if CHT exceeds 420*F, reduce power if safely able to do so.
Temperature ˚F
-30 -20 -10 ISA 10 20 30
Pressure Altitude
RPM for 80 Horsepower
Sea level 2050 2050 2050 2050 2050 2100 2100
2000 feet 2100 2100 2100 2100 2100 2100 2100
4000 feet 2150 2150 2150 2150 2150 2150 2200
6000 feet 2200 2200 2200 2200 2200 2200 2200
8000 feet 2250 2250 2250 2250 2250 2250 2300
10000 feet 2300 2300 2300 2300 2300 2300 2300
