HYDRAULIC SYSTEM PURGING
1. Open the release valve by turning it two full turns counter-clockwise.
2. Pump the handle four full strokes quickly.
3. Close the release valve by turning it clockwise.
4. Pump the handle with full strokes to check if it can reach the maximum height within ten
pumps.
If it can’t reach the maximum height within ten pumps, please refer to the following special
purging process:
5. Open the release valve by turning counter-clockwise and lower the lifting arm to the
minimum height.
6. Put the jack on a at working table, lift the front part of
the jack to make sure the front part is at least 18” higher
than the back part of the jack. See the following photo.
7. Pump the handle four full strokes quickly.
8. Put the jack on a at surface and close the release valve
by turning it clockwise.
9. Pumping the handle with full strokes to check if it can
reach the maximum height within ten pumps. If not
please repeat the special purging process again.
OPERATING INSTRUCTIONS
WARNING: ENSURE THAT YOU READ, UNDERSTAND AND APPLY THE SAFETY
INSTRUCTIONS AND WARNINGS BEFORE USE. FAILURE TO HEED THESE INSTRUCTIONS
MAY RESULT IN PROPERTY DAMAGE AND/OR PERSONAL INJURY.
RAISING A VEHICLE
1. Ensure that the jack and the vehicle are on a hard, level surface.
2. Always ensure that the vehicle parking brake is engaged and that the vehicle wheels are
chocked.
3. Consult the vehicle manual to determine the location of jacking points. Position the jack
under a suitable lifting point.
4. Turn the handle clockwise, to close release valve. DO NOT over-tighten.
5. Raise the vehicle to the desired height by pumping the handle up and down.
6. Place jack stands beneath the locations recommended by the vehicle manufacturer.
7. Turn the release valve slowly counter-clockwise to lower the vehicle on to the jack
stands.
