TTB517STP by TITAN
Getting started...
GB
Before you start
Inserting Nails and Staples
IE
Only use the nails/staples which are outlined in the technical specifications.
Please keep in mind that nails/staples must be suited to the material they are
used in.
The harder the material is, the shorter the staples or nails should be.
1. Press lever (1) while pulling slider (9) backwards
2. Insert the nail strip into magazine (8) with heads facing upward (maximum
capacity 100/nails)
3. Push slider (9) against nailer head (4) until it snap locks.
4. When inserting a nail/staple strip, it rests against the magazine side which
correponds with the nail symbol on nailer head (4).
Fig. 1
9
8
1
4
A
B
C
Fig. 2
