Getting started...
14
Your product / Before you start
General
> Rated voltage, frequency : 220 - 240 V~ , 50 Hz
> Nominal power : 1.5HP/1.2kW
> Rated no load speed n
0
: 3450 min
-1
> Degree of protection :
IP30
> Protection class :
I
> Weight : 15.5 kg
> Dimensions : 580 x 275 x 520 mm
Compressor
> Operating pressure : 8 bars
> Maximum allowable pressure at the
outlet of the compressor : 8 bars
> Pressure vessel capacity : 24 l
> Intake rate (theoretical) : approx. 180 l/min
> Pump-up time : 150 s
> Recovery time : 40 s
> Minimum operating temperature : + 5 °C
> Maximum operating temperature : + 40 °C
Sound values
> Sound pressure level L
pA
: 76 dB(A)
> Sound power level L
WA
: 96 dB(A)
> Uncertainty K
pA
, K
WA
: 3 dB(A)
The sound values have been determined according to noise test code given in
EN 1012-1, using the basic standard EN ISO 2151.
The sound intensity level for the operator may exceed 80 dB(A) and ear
protection measures are necessary.
TTB797CPR
TT = TITAN
B = 240V AC
797 = Version number
CPR = Compressor
Unpacking
>
> Remove all packing materials and shipping devices, if applicable.
