Dimensions
This diagram details the overall size of the unit
Component Identication
Patent applied for APPLICATION NUMBER 2004732.0
Ø195
119CRS*
119CRS*
*Fixing Holes
45 71
Ø100
7
Controls
Top
Fascia
Base
Top Retaining Screw x 4
