IOM - ALPHA CONTROLLER
Redefine your comfort zone. ™ | www.titus-hvac.com
IOM
BAC-8007/BAC-8207
Section 2 — Installing the Controller
This section provides important instructions and guidelines for installing
the BAC-8007 and BAC-8207 controllers. Carefully review this information
before installing the controller.
Installing the VAV controller includes the following topics that are covered
in this section.
• Setting the rotation limits on page 9
• Mounting on page 10
• Connecting Inputs on page 14
• Connecting Outputs on page 12
• Connecting to an MS/TP Network on page 14
• Connecting an Airflow Sensor on page 17
• Connecting Power on page 17
In addition to the topics, see the section Dual-duct connections on page
18 for connecting the controllers to a TSP-8000 actuator for dual-duct
operation.
