TLR EIGHT 4.0 - Front Suspension; Differentials; Rear Suspension; Engine

65
Differentials
4
3
2
1
3
2
4
1
4
3
2
1
6 3
5 2
4 1
Front: Standard Smart
Spring Wire Dia._________
Qty of Springs: _________
Ramp Plate: ___________
Grease: _______________
Diff Fluid: _____________
Center:
Standard Smart
Spring Wire Dia.:________
Qty of Springs: _________
Ramp Plate: ___________
Grease: _______________
Diff Fluid: _____________
Roll Center: HRC LRC
Toe: ________________________________________________
Anti-Squat: ___________________________________________
Ride Height: __________________________________________
Camber:______________________________________________
Rear Hub Spacing: ______________________________________
Wheel Hex: ___________________________________________
Sway Bar: ____________________________________________
Piston/Oil: ____________________________________________
Shock Type: Bladder Emulsion
Spring: _______________________________________________
Limiter/Droop: _________________________________________
Overall Shock Length: ___________________________________
Camber Link: __________________________________________
Shock Position: _________________________________________
Rear Diff Fluid: _________________________________________
Toe:__________________________
Ride Height: ___________________
Camber: ______________________
Caster: _______________________
Spindle Height: High Low
Wheel Hex: ____________________
Sway Bar: _____________________
Piston/Oil: _____________________
Shock Type: Bladder Emulsion
Spring: _______________________
Limiter/Droop: _________________
Overall Shock Length: ___________
Steering Ackerman: _____________
Bump Steer: ___________________
Camber Link: __________________
Shock Location: ________________
Receiver Battery Type: ___________
Engine: ______________________
Glow Plug: ___________________
Pipe/Header: __________________
Clutch Shoes and Springs Info
Front: ______________ _____________ _____________
Rear: _______________ _____________ _____________
Notes: ___________________________________________
_________________________________________________
_________________________________________________
Type Compound Insert
Notes: ______________________________________
____________________________________________
____________________________________________
____________________________________________
Notes: ______________________________________
____________________________________________
____________________________________________
____________________________________________
Fuel: __________________
Head Clearance__________
Gearing: _______________
Wing Type: 2.0 3.0
Wing Spacer: .250 .500
Wicker Bill: .250 .350
3000 wt
Long
1º Toe Out
-2º
2.3mm
8 Hole 1.3mm/40 wt
Green 4.8 lbs.
103.5mm
3/Outside
Up
2
29mm
8IGHT 4.0 Standard Setup
3º
3º
29mm
-2º
Back
2.3mm
8 Hole Split 1.2mm & 1.3mm/25wt
Silver 3.6 lbs
114mm
2/B
3/Outside
27º
7000 wt
5000 wt



Standard Hex
+1mm Hex






