Toa A-2060D Series User Manual

Model no.
Dimensions
Finish
Indicator
Muting
Tone Control
S/N Ratio
Output
Phantom Power
Input
Distortion
Frequency Response
Rated Output
Power Source
Weight
A-2030DD-EB
420 (w) x 100.6 (h) x 280.3 (d) mm (16.54” x 3.96” x 11.04”)
Panel : ABS Resin, Black
POWER, PEAK, SIGNAL
MIC 1 : mute other input signal by 0-30dB attenuation
Bass
±10dB at 100Hz
Over 60dB
Balanced (Floating)
DC +21V (MIC 1)
-60 dB (0dB=1V), 600Ω, Balanced, 5-P DIN type
-60 dB (0dB=1V), 600Ω, Balanced, Phone jack
Less than 1% at 1kHz, 1/3 Rated Power
50-20000Hz,
±3dB
30W
220-240V 50/60Hz
4.0 kg (8.88 lb)
Power Consumption
(EN 60065)
12W
330Ω
Speaker out
-20 dB (0dB=1V), 10kΩ, Unbalanced, RCA pin jack
MIC 1
MIC 2-3
AUX 1-2
Mute : contact pin 4-5 closure to input (for MIC1) Mute
Line 100V
0dB (1V), 600Ω, Unbalanced RCA pin jackRec Out
Treble
±10dB at 10kHz
Case : Steel Plate, Black
A-2060DD-EB
60W
4.6 kg (10.14 lb)
16W
170Ω
A-2120DD-EB
120W
4.0 kg (8.88 lb)
34W
83Ω
A-2240DD-EB
240W
4.0 kg (8.88 lb)
48W
42Ω
*Design & specification are subject to change without notice for improvement.
11
[A-2000DD-EB 1CE Series, A-2000DD-EB 4CE Series]
[A-2000DT-AS 2CE Series]
Model no.
Dimensions
Finish
Indicator
Muting
Tone Control
S/N Ratio
Output
Phantom Power
Input
Distortion
Frequency Response
Rated Output
Power Source
Weight
420 (w) x 100.6 (h) x 280.3 (d) mm (16.54” x 3.96” x 11.04”)
Panel : ABS Resin, Black
POWER, PEAK, SIGNAL
MIC 1 : mute other input signal by 0-30dB attenuation
Bass ±10dB at 100Hz
Over 60dB
Balanced (Floating)
DC +21V (MIC 1)
Less than 1% at 1kHz, 1/3 Rated Power
50-20000Hz,
±3dB
Power Consumption
(EN 60065)
Speaker out
-60 dB (0dB=1V), 600Ω, Balanced, XLR3 -31 type
-20 dB (0dB=1V), 10kΩ, Unbalanced, RCA pin jack
MIC 1-3
AUX 1-2
6 Tone contact trigger (chime, Bell, Evac, Alert, Lockdown, Clear)
will be mute the other function
TONES
Line 100V
0dB (1V), 600Ω, Unbalanced RCA pin jackRec Out
Treble
±10dB at 10kHz
Case : Steel Plate, Black
A-2120DT-AS
120W
4.0 kg (8.88 lb)
34W
83Ω
A-2240DT-AS
240W
4.0 kg (8.88 lb)
48W
42Ω
*Design & specification are subject to change without notice for improvement.
220-240V 50/60Hz

Toa A-2060D Series Specifications

General

Brand	Toa
Model	A-2060D Series
Category	Amplifier
Language	English
