11. CHARACTERISTIC DIAGRAM
F-160 Series Frequency Response (1 W/1 m)
F-160 Series Directional Characteristics
Vertical
Horizontal
1000
Hz
2000 Hz
4000 Hz
8000 Hz
10 dB/Div.
F-240 Series Frequency Response (1 W/1 m)
F-240 Series Directional Characteristics
Vertical
Horizontal
1000
Hz
2000 Hz
4000 Hz
8000 Hz
10 dB/Div.
TOA Corporation
8
