Congure TOA IP Audio Systems for the CyberGate serviceCyberTwice
2
TOA IP Audio Systems
For this document the following TOA IP Audio equipment is used to connect to the CyberGate service
(from now on named ‘CyberGate’).
This document applies to the following TOA devices:
• TOA IP Paging Gateway IP-A1PG
• TOA IP Audio Interface IP-A1AF
• TOA IP Ceiling speaker IP-A1PC238
• TOA IP Ceiling Speaker IP-A1PC580R
The following scenarios are tested:
1. The IP Audio Interface and the two IP Ceiling speakers each have an individual SIP connection to
CyberGate. The IP Audio Interface has an attached speaker, microphone and switch, so initiating
calls to Teams using the switch is also possible (it will act as an intercom)
2. The IP Paging Gateway has a SIP connection to CyberGate and uses Multicast to connect to the
IP Audio Interface and the two IP Ceiling speakers (zone-paging)
! Note: In scenario 2 (using the IP Paging Gateway) the audio is Paging only (one-way
audio). Scenario 1 als supports audio from a microphone to Microsoft Teams (two-way
audio). !
Scenario 1
