14. SPECIFICATIONS
14.1. Line Array Speaker SR-S4L, SR-S4S
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Bi-amplifier rating label ................................... 1
Bi-amplifier terminal label ................................ 1
• Optional products
Matching transformer: MT-S0601
Extension plate: SR-EP4
Flying bracket: SR-FB4
Wall tilt bracket: SR-TB4
Wall mounting bracket: SR-WB4 (Applicable to the SR-S4L only)
Floor stand: SR-FS4 (Applicable to the SR-S4L only)
Stand adapter: SR-SA4
Protection pad: SR-PP4
Digital processor: DP-0206
Model No. SR-S4L SR-S4S
Enclosure Bass-reflex type
Power Handling Capacity Continuous program: 600 W
Rated Impedance 8 Ω
Sensitivity 94 dB (1 W, 1 m) 93 dB (1 W, 1 m)
Frequency Response 70 – 20,000 Hz (when using the optional DP-0206 Digital processor)
Crossover Frequency 3,500 Hz
Directivity Angle Horizontal: 90° Horizontal: 90°
Vertical: 0° (within the range of Vertical: 10°
speaker height)
Speaker Component Low frequency: 10 cm cone-type x 8
High frequency: 2.5 cm balanced dome-type x 24
Input Connector M5 screw terminal, distance between barriers: 12.2 mm
and Neutrik NL4MP x 2 (usable cable connector: Neutrik NL4FC)
Finish Enclosure: MDF, white, paint
Front grille: Punched steel plate, white, acrylic paint
Dimensions 160 (w) x 895 (h) x 255 (d) mm 160 (w) x 892 (h) x 303 (d) mm
Weight 16 kg
