3. SYSTEM SUMMARY
TOA's SX-2000 series Matrix systems are input and output signal routing processing systems that function as
the core for multi-channel general-purpose broadcast systems, and are designed for use in such locations as
shopping centers, department stores and shop/store complexes. The SX-2000 systems are designed to
distribute remote microphone outputs, automatic guidance broadcasts, background music, and sounds from
other connected sources to power amplifiers via an audio signal/control signal matrix with 16 digital busses
using pre-determined conditions and priorities.
The SX-2000 system allows 3 types of broadcasts to be made: General-purpose broadcast such as general
paging and BGM, Emergency broadcast that the emergency messages are to be broadcast by an automatic
announcement device or remote microphone, and General urgency all-call broadcast* that is to be made
available even during system malfunctions or failures.
The dedicated software is used to perform all necessary settings related to the entire system operation and
functions including system configurations, input-to-output signal routing, function assignment to the operation
keys, operation of the control terminals, and selection of the failure detection points.
* Available when an analog link is connected.
2. COMPOSITION OF THE SX-2000 INSTRUCTION MANUAL
The SX-2000 system Instruction manual is divided into 4 parts.
Please read the proper manual for your purpose.
This manual
(PLEASE READ THIS MANUAL FIRST)
For broadcast management and setup
For broadcasting operation
Separate Manual
(Print and CD)
Separate Manual
(CD only)
Operating Instructions
For unit installation
Setting Software Instructions
Installation Manual
To Next Page
