Recommended monitor size
The X60/X120 Monitor Mount is constructed for monitors between 17’’ and 23.5’’, i.e. with a diagonal
between 43.2 and 59.7 cm. The shape of the area in which maximum precision and accuracy can be
achieved is illustrated below. When choosing which monitor to use with the X60/X120 Monitor Mount,
consider the shape of the monitor as well as the size.
What is included
When you open the box you will find two boxes; one containing the X60/X120 Monitor Mount and
one containing the arm. You will also find this user guide, a digital angle gauge and an additional
VESA
®
adapter plate.
The X60/X120 Monitor Mount box contains:
The X60/X120 Monitor Mount body including attached screws•
9 screws•
2 Allen wrenches•
The LCD arm box contains:
A desk clamp•
An assembly arm•
A monitor tilter unit•
A cable coverage kit•
A bag of screws and other assembly details•
A VESA•
®
adapter kit
Box content
