14
Bracket
<Assembling>
When assemble drive shaft housing parts, reverse the disassembling procedure.
Tightening torque as follows:
*Notes
Put in the dowel pin and assemble.
Connect ground wire.
Engine base seal rubber is certainly attached to the engine base.
Lower unit
＜Disassembly＞
Size x Q'ty 1 st
Engine mount bolt 1.9-2.1kg.m
Bracket nut 2.4-2.6kg.m
Mount rubber(upper) 4.0-5.0kg.m
Mount rubber(lower) 3.5-4.5kg.m
M8 2.4-2.6kg.m
M10 3.8-4.2kg.m
Gear case mount bolt
