7
Fuel hose to fuel filter (In side)
Pilot hose connection
After removing each connection, remove an apron and engine attachment bolts.
Remove carburetors and inlet manifold.
Loose flywheel nut using special tool (Flywheel Puller kit 3C7-72211-1)
Remove flywheel from crankshaft using special tool (Flywheel Puller).
Remove oil re-circulation hose.
Remove, crank case mounting bolts and crankshaft from crankcase.
(Be careful not to damage the piston and piston ring)
