SPECIFICATIONS 13
2
ENOM00013-0
ET
Item MODEL
F40A/50A/60A
ET
(with RC)
ET (with multi-function
tiller handle)
Overall Length mm (in) 783 (30.8)
type I: 1382 (54.4),
type II 1434 (56.5)*1
Overall Width mm (in) 404 (15.9)
Overall Height S·L·UL mm (in) 1257 (49.5) 1390 (54.7) 1504 (59.2)
Transom Height S·L·UL mm (in) 405 (15.9) 538 (21.2) 652 (25.7)
Weight*2
S kg (lb) 96.5 (213), 60A: 98 (216) 101.5 (224), 60A: 103.0 (227)
L kg (lb) 98.5 (217), 60A: 100.0 (220) 103.5 (228), 60A: 105.0 (231)
UL kg (lb) 60A: 103.0 (227) 60A: 108.0 (238)
Max. Output kW (ps) 40A : 29.4 (40) 50A : 37 (50) 60A : 44 (60)
Max. Operating Range
min
-1
(rpm)
5000–6000
Idle Speed
min
-1
(rpm)
850
Engine Type 4-Stroke fuel injection
Number of Cylinder 3
Bore × Stroke mm (in) 70 × 75 (2.75 × 2.95)
Piston Displacement mL (Cu in) 866 (52.8)
Exhaust System Through hub exhaust
Cooling System Water cooling (with thermostat)
Engine Lubrication Wet sump (Trochoid pump)
Starting System Electric starter motor
Ignition System Battery ignition
Spark Plug NGK IKR6G8
Alternator 12V 25A
Trim position 4
Trim angle Degree 8-20
Tilt up angle Degree 74
Steering angle Degree 70
Engine Oil
Grade API standard SH, SJ, SL, SAE10W-30/40
mL (US qt) 2200 (2.3)
Gear Oil
Grade Genuine Gear Oil or API GL5, SAE #80-90
mL (US qt) 500 (0.53)
Fuel Unleaded Regular Gasoline : R+M/2: 87 or higher RON: 91 or higher
Fuel Tank Capacity L (US gal) 25 (6.60)
Gear shift Dog clutch ( F-N-R)
Gear Reduction Ratio 2.08 (13:27)
