For Tiller handle model
High speed ESG (Electronic Safety Governor)
High speed ESG is a device to prevent over revolution of the engine. If the load to the engine becomes light for
some reason, it runs at a higher speed than the usual. In such the case, the buzzer sounds and the ESG is
activated not to ignite the spark plug, therefore, the engine speed varies and be controlled under 6200 min
-1
(rpm).
Low speed ESG
Low speed ESG is a device to prevent the engine from getting damage. If the engine has problems regarding
cooling water, oil pressure, and sensors, the low speed ESG is activated not to ignite the spark plug, and disable
fueling therefore, the engine speed varies and be controlled under 3000 min
-1
(rpm).
Warning indicators
E S G
Description of faults
or notice
Remark
Rem-
edy
Sound
A
lamp
B
lamp
C
lamp
Continu-
ous
ON ON ON -
Normal system test
when key on
1 second
Continu-
ous
- - -
High
speed
ESG
Engine speed exceeds
maximum
allowable RPM
Approx.
6,200 min-1 (rpm)
1
Continu-
ous
ON - -
Low
speed
ESG
Low oil pressure 2
Continu-
ous
-
Flash-
ing
-
Low
speed
ESG
Cooling water temp. is
high
Over
85°C/185°F
3
Continu-
ous
Flash-
ing
Flash-
ing
Flash-
ing
Forced
ideling
Cooling water temp. is
abnormally high
Over
140°C/284°F
3
-
- -
Flash-
ing
- Battery voltage is low
Engine is stopped
under 9V
4
-
Flash-
ing
Flash-
ing
Flash-
ing
Low
speed
ESG
Malfunction of sensor 5
-
Flash-
ing
Flash-
ing
Flash-
ing
-
Malfunction of electrical
part
5
-
Flash-
ing
- - -
Inform the recommended
timing of engine oil
replacement (every
100hrs.)
“A lamp” ON 1 sec. and
OFF 9 sec.
6
One beep
- - - -
Lowest idling speed of
variable idling system
Two beep
- - - -
Highest idling speed of
variable idling system
