INSPECTION AND MAINTENANCE66
10
ENOM00081-D
Oil level checking
If the oil level is low, or too high, the life
of the engine will be shortened signifi-
cantly.
1. Place the engine in a vertical position.
2. Remove the top cowl.
3. Remove the dipstick.
4. Wipe oil off the dipstick with a clean
cloth.
5. Insert the dipstick to the hole com-
pletely.
6. Remove the dipstick again. Check the
oil level on the dipstick. Oil level must
be between the upper limit and lower
limit shown on the dipstick.
7. Return the dipstick.
1. Filler cap
2. Dipstick
1. Upper level 2200 mL
2. Lower level 1700 mL
ENON00024-0
Note
The oil level should be checked when the
engine is cooled.
ENON00025-0
Note
Consult with an authorized dealer if the
engine oil is milky color, or appears con-
taminated.
ENOM00082-A
Engine oil replenishing
ENOW00079-A
z Do not add engine oil of brand and grade
other than existing one. In case engine oil
of other brand or grade is added, drain all
oil and ask dealer for treatment.
z In case other than engine oil such as gaso-
line is put in the oil chamber, empty the
chamber and ask dealer for treatment.
z When replenishing engine oil, be careful
not to allow entry of foreign matters such
as dust and water into oil chamber.
Steering
Devices
• Check the operation of the steering handle. Repair
Other parts
• Check if the anode is securely installed. Repair if necessary
• Check the anode for corrosion and deformation. Replace
Item Points to Check Remedy
CAUTION
2
1
ENOF00081-0
To Next Page
