PRE-OPERATING PREPARATIONS26
6
1. When using integral tank
Full open the air vent screw on the
tank cap and release internal pressure.
1. Air vent screw
2. Fuel tank cap
When using separate tank
1. Full open the air vent screw on the
tank cap and release internal pres-
sure.
1. Air vent screw
2. Fuel tank cap
2. When using integral tank
Open the fuel tank cap slowly.
When using separate tank
Loosen the tank cap until it con-
tacts the tab lock and release inter-
nal pressure completely. After that,
press down the tab lock and open the
tank cap.
3. When using integral tank
Remove top cowl and fill the fuel not
to over the full mark.
When using separate tank
Fill the fuel carefully not to over flow.
1. Full mark
4. After filling the tank, close the fuel
tank cap until two clicks sound is
heard.
1
2
ENOF00421-1
SAFE FILL
LEVEL
12 L
NIVEAU
MAXIMUM
ENOF00419-A
