Rear Support
1. Locate the longer, straight tube from the loose parts.
2. Remove the bolt and washer from each end of the tube.
3. Align the pre-drilled holes in each end of the tube with the pre-
drilled holes in each side support.
4. Place a washer on each bolt, for each side, insert a bolt
through all pre-drilled holes and tighten. NOTE: Do not tighten
the bolts all the way. Leaving slight movement in the supports
will allow for easier assembly.
Cross Support
1. Locate the “X” shaped tube from the loose parts.
2. Remove the bolts and washers from each of the four contact
points.
3. Align the pre-drilled holes in each end of the “X” cross support
with the pre-drilled holes in each side support. IMPORTANT:
The top half of the “X” cross support is shorter than the bottom
half. The top two contact points on the “X” cross support should
15
