Page 96 VANISH Operator’s Manual
EXPLANATION
The charger is computer-controlled and will monitor and •
maintain your batteries’ peak condition.
The AC side of the charger uses a three prong plug.
•
While charging, use a three prong wall receptacle with a
proper ground.
If the charger is left connected to AC power supply, a refresh
charge will occur after 10 days if the battery voltage has
dropped below a pre-programmed level. If a refresh charge
tries to start, but the AC power is disconnected, the charger
will wait 8 days for AC to be restored. At this point, the charger
will go into sleep mode and a DC disconnect will be required
to reset the charger, visit your Tomberlin dealer to reset the
charger.
OUTLET AND CORD TYPE
Use any three-prong 110-240 volt home outlet•
Must have available minimum 15 amps of current•
To avoid the risk of electrical shorting, the battery charger must
be grounded through a properly installed three prong outlet. Do
not use an adapter plug to go from three prongs to a two prong
outlet. This will result in an ungrounded condition and increase
the risk of electrical shock and/or re.
When using an extension cord, avoid excessive 1.
voltage drops by using a grounded, 3-wire, 10-AWG
cord no longer than 30m (100’).
Use the proper cord wire gauges for the cord length
2.
used:
Length: <25 ft. (7.5 m) <50 ft. (15 m) <100 ft. (30 m)
Gauge: 16 AWG
(1.5 mm2)
14 AWG
(2.5 mm2)
10 AWG
(6.0 mm2)
AVOID connecting the QuiQ charger and another device to a
single 15A/20A circuit or the circuit may become overloaded.
